BC Racing DS Series Coilovers – BMW 3 Series (E46) True Rear Coilover 1998-2006

BC Racing SKU: 0070912
Regular price Price: £1,214.10
Regular price £1,278.00 Sale Sale price Price: £1,214.10
Spring Rate
Accepted payment methods
  • American Express
  • Apple Pay
  • Bizum
  • Diners Club
  • Discover
  • Google Pay
  • Klarna
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Satispay
  • Shop Pay
  • Union Pay
  • Visa

Do you have questions about this product?

📞 Ask an Expert!

BC Racing's DS Coilover system is built with digressive valving offering the same great benefits of the BR model and is considered a perfect choice for those looking for track-biased coilovers. The digressive piston design gives a non-linear damping curve which allows higher low-speed damping to control body roll through cornering, acceleration and braking, whilst providing reduced high-speed damping to allow the wheel to travel over kerbs, retaining car balance.

Key features:

  • Digressive piston and damping curve
  • Satin chrome finished shock body
  • 30 clicks of simultaneous rebound and compression adjustment
  • Ride height adjustment separate to spring preload
  • Camber adjustable top mounts (depending on model)
  • Pillowball top mounts
  • Bearing mounted upper spring platform
  • Dust boot to protect the damper seal
  • Tapered bottom mount locking collar
  • Custom spring rates available
  • All spare parts available with low lead times
  • 1 year manufacturer warranty

Configuration options:

  • DA — Aluminium camber adjustable pillowball top mounts on the front (where available) and aluminium rear top mounts with rubber centres or no rear top mounts.
  • DN — Supplied without front top mounts and with aluminium rear top mounts with rubber centre or no rear top mounts.

Fitment: BMW 3 Series E46 RWD (Exc M3) (Integrated Rear), 1998-2006.

Custom spring rates available on request.

Vehicle Fitment

Make Model Chassis Models Years
BMW 3 Series E46 All models 1998–2006

BC Racing part numbers

Spring rate APEX SKU BC part SKU Series Type BC product name
6/5KG.MM 0070912 I-31-DS-DH DS — BMW 3 SERIES SEDAN E46 (98-06) 6/5KG.MM
10/12kg.mm 0009897 I-31-DS-DH DS — BMW 3 SEDAN/COUPE (True Rear) E46 10/12kg.mm
10/6KG.MM 0029134 I-31-DS-DH DS — BMW 3 SERIES SEDAN E46 (98-06) 10/6KG.MM
8/5kg.mm 0029837 I-31-DS-DH DS — BMW 3 SEDAN/COUPE (Rear Integrated) E46 (98-06) 8/5kg.mm
12/6kg.mm 0035527 I-31-DS-DH DS — BMW 3 SEDAN/COUPE (Rear Integrated) E46 (98-06) 12/6kg.mm
8/7kg.mm 0080369 I-31-DS-DH DS — BMW 3 SEDAN/COUPE (Rear Integrated) E46 (98-06) 8/7kg.mm
8/10kg.mm 0090118 I-31-DS-DH DS — BMW 3 SEDAN/COUPE (Rear Integrated) E46 (98-06) 8/10kg.mm
12/5kg.mm 0090430 I-31-DS-DH DS — BMW 3 SEDAN/COUPE (Rear Integrated) E46 (98-06) 12/5kg.mm
10/8kg.mm 0090498 I-31-DS-DH DS — BMW 3 SEDAN/COUPE (Rear Integrated) E46 (98-06) 10/8kg.mm
