H&R TRAK+® Wheel Spacers 3mm (6mm per axle), 4x100/108, 57.1mm bore, Silver for VW - 06234571

H&R SKU: 06234571
Regular price Price: £70.40
Sale ends in
Days
Hours
Minutes
Seconds
Accepted payment methods
  • American Express
  • Apple Pay
  • Bizum
  • Diners Club
  • Discover
  • Google Pay
  • Klarna
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Satispay
  • Shop Pay
  • Union Pay
  • Visa

Do you have questions about this product?

📞 Ask an Expert!

H&R TRAK+ wheel spacers push the wheels outward to improve stance, track width and clearance. Precision-machined and hub-centric for a perfect, vibration-free fit. Please note the correct bolt/cone type and length — longer wheel bolts are required for DR-system spacers and are ordered separately.

Features

  • Improved stance and wider track
  • Hub-centric, precision-machined
  • Application-specific fitment
  • TÜV-certified versions available

Specification

  • Thread Size: M12x1,5
  • Colour: silver
  • Thickness (mm): 3
  • Track widening per axle (mm): 6
  • Number of holes: 4
  • Registration: without TÜV® certificate

For all cars with 4-hole wheel.
Only valid in Germany
Please note additional information and vehicle-specific technical notes!
DR = The wheel spacer should be fitted between the wheel and the axial hub using longer bolts not supplied - please order separately. When ordering the longer bolts please state which cone type you require (i.e. taper, round, loose round or flat) and the required extra length. All screws for the DR systems have to be orderded separately.
All DR-Systems require longer wheel-bolts. These have to be ordered separately. When ordering wheel-bolts please follow these guidelines: If possible name the type of the wheel when ordering. New bolts must be longer than the original ones by half of the total Track-widening. For example: With a 30 mm DR-kit you will require bolts that are 15 mm longer than the original bolts. The bold-head must be identical to the existing bolt: Taper 60° Round-head for M12/d24 mm, for M14/d28 mm Round-head for M12/d26 mm (e.g. OE VAG-wheels) Flat-head with disc for CITROEN/PEUGEOT-vehicles M12x1,25 Flat-head for PORSCHE-original-wheels M14x1,5 Safety Guidelines (No. of turns for wheel screws) M12x1,5 = 6,5 turns = approx. 10 mm of load bearing shaft length M12x1,25 = 8,0 turns = approx. 10 mm of load bearing shaft length M12x1,75 = 6,5 turns = approx. 12 mm of load bearing shaft length M14x1,5 = 7,5 turns = approx. 12 mm of load bearing shaft length 1/2"UNF = 8,0 turns = approx. 11 mm of load bearing shaft length Please ensure that the wheel screws do not damage any part of the brake system (ABS sensors etc.) Turn the wheel first by hand and check clearance on the inside (max. tolerance for some vehicles is only 2 mm (RA Mercedes).
These spacers without a double-sided centering are only useable for cars with a sufficient length of the centering to be able to center the wheels enough despite the spacer.

Product information (PDF) · Installation manual (PDF)

Vehicle Fitment

Make Model Chassis Models Years
Volkswagen Golf MK1 All models 1974–1993
Volkswagen Scirocco 53 All models 1974–1980
Volkswagen Jetta MK1 All models 1978–1984
Volkswagen Scirocco 53B All models 1980–1992
Volkswagen Polo 86C All models 1981–1994
Volkswagen Golf MK2 All models 1983–1992
Volkswagen Jetta MK2 All models 1984–1992
Volkswagen Corrado 53I All models 1988–1995
Volkswagen Passat B3 All models 1988–1993
Volkswagen Golf MK3 All models 1991–1998
Volkswagen Vento 1H All models 1991–1998
Volkswagen Passat B4 All models 1994–1997
Volkswagen Polo 6N All models 1994–2006
