H&R TRAK+® Wheel Spacers 8mm (16mm per axle), 5x100/112, 57.1mm bore, Silver for Audi, VW, Seat & Skoda - 162555716

H&R SKU: 162555716
Regular price Price: $105.00
Sale ends in
Days
Hours
Minutes
Seconds
Accepted payment methods
  • American Express
  • Apple Pay
  • Bizum
  • Diners Club
  • Discover
  • Google Pay
  • Klarna
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Satispay
  • Shop Pay
  • Union Pay
  • Visa

Do you have questions about this product?

📞 Ask an Expert!

H&R TRAK+ wheel spacers push the wheels outward to improve stance, track width and clearance. Precision-machined and hub-centric for a perfect, vibration-free fit. Please note the correct bolt/cone type and length — longer wheel bolts are required for DR-system spacers and are ordered separately.

Features

  • Improved stance and wider track
  • Hub-centric, precision-machined
  • Application-specific fitment
  • TÜV-certified versions available

Specification

  • Thread Size: M14x1,5
  • Colour: silver
  • Track widening per axle (mm): 16
  • Number of holes: 5
  • Registration: with TÜV® certificate

For cars with 5-hole wheels.
Not usable with steel-rims!
Please note additional information and vehicle-specific technical notes!
Only for the front axle.
DR = The wheel spacer should be fitted between the wheel and the axial hub using longer bolts not supplied - please order separately. When ordering the longer bolts please state which cone type you require (i.e. taper, round, loose round or flat) and the required extra length. All screws for the DR systems have to be orderded separately.
All DR-Systems require longer wheel-bolts. These have to be ordered separately. When ordering wheel-bolts please follow these guidelines: If possible name the type of the wheel when ordering. New bolts must be longer than the original ones by half of the total Track-widening. For example: With a 30 mm DR-kit you will require bolts that are 15 mm longer than the original bolts. The bold-head must be identical to the existing bolt: Taper 60° Round-head for M12/d24 mm, for M14/d28 mm Round-head for M12/d26 mm (e.g. OE VAG-wheels) Flat-head with disc for CITROEN/PEUGEOT-vehicles M12x1,25 Flat-head for PORSCHE-original-wheels M14x1,5 Safety Guidelines (No. of turns for wheel screws) M12x1,5 = 6,5 turns = approx. 10 mm of load bearing shaft length M12x1,25 = 8,0 turns = approx. 10 mm of load bearing shaft length M12x1,75 = 6,5 turns = approx. 12 mm of load bearing shaft length M14x1,5 = 7,5 turns = approx. 12 mm of load bearing shaft length 1/2"UNF = 8,0 turns = approx. 11 mm of load bearing shaft length Please ensure that the wheel screws do not damage any part of the brake system (ABS sensors etc.) Turn the wheel first by hand and check clearance on the inside (max. tolerance for some vehicles is only 2 mm (RA Mercedes).
Note 18b: For the usage of these spacers certain specific technical requierements need to be fulfilled! Please check product information document TRAK_HINWEISE.pdf note 18b!
If the attachmet face is too small, spacers with an outer diameter of 150mm are available alternatively. Please find below the part numbers for these: DR-System 16 mm = 162555719 DR-System 24 mm = 242555713 DR-System 40 mm = 402555716 DRA-System 50 mm = 50255712

Product information (PDF) · Installation manual (PDF)

Vehicle Fitment

Make Model Chassis Models Years
Audi A3 8L All models 1996–2003
Audi TT 8N All models 1998–2006
Audi A2 8Z0 All models 2000–2005
Volkswagen Passat B3 All models 1988–1993
Volkswagen Golf MK3 All models 1991–1999
Volkswagen Vento 1H All models 1991–1998
Volkswagen Passat B4 All models 1994–1997
Volkswagen Golf MK4 All models 1997–2008
Volkswagen Bora 1J All models 1998–2013
Volkswagen Beetle 9C All models 1998–2010
Volkswagen Polo 9N All models 2001–2009
Volkswagen Fox 5Z All models 2003–2021
Volkswagen Polo 6R All models 2009–2022
Seat Toledo 1M All models 1998–2006
Seat Leon 1M All models 1999–2006
Seat Cordoba 6L All models 2002–2009
Seat Ibiza 6L All models 2002–2009
Skoda Octavia 1U All models 1996–2010
Skoda Fabia 6Y All models 1999–2008
Skoda Superb 3U All models 2001–2008
Skoda Roomster 5J All models 2006–2015
