H&R TRAK+® Wheel Spacers - 20145802

H&R SKU: 20145802
Regular price Price: $123.00
Sale ends in
Days
Hours
Minutes
Seconds
Accepted payment methods
  • American Express
  • Apple Pay
  • Bizum
  • Diners Club
  • Discover
  • Google Pay
  • Klarna
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Satispay
  • Shop Pay
  • Union Pay
  • Visa

Do you have questions about this product?

📞 Ask an Expert!

H&R TRAK+ wheel spacers push the wheels outward to improve stance, track width and clearance. Precision-machined and hub-centric for a perfect, vibration-free fit. Please note the correct bolt/cone type and length — longer wheel bolts are required for DR-system spacers and are ordered separately.

Features

  • Improved stance and wider track
  • Hub-centric, precision-machined
  • Application-specific fitment
  • TÜV-certified versions available

Specification

  • Thread Size: M12x1,25
  • Colour: silver
  • Thickness (mm): 10
  • Track widening per axle (mm): 20
  • Number of holes: 4
  • Bolt hole circle Ø (mm): 98
  • Registration: with TÜV® certificate

Please note additional information and vehicle-specific technical notes!
DR = The wheel spacer should be fitted between the wheel and the axial hub using longer bolts not supplied - please order separately. When ordering the longer bolts please state which cone type you require (i.e. taper, round, loose round or flat) and the required extra length. All screws for the DR systems have to be orderded separately.
All DR-Systems require longer wheel-bolts. These have to be ordered separately. When ordering wheel-bolts please follow these guidelines: If possible name the type of the wheel when ordering. New bolts must be longer than the original ones by half of the total Track-widening. For example: With a 30 mm DR-kit you will require bolts that are 15 mm longer than the original bolts. The bold-head must be identical to the existing bolt: Taper 60° Round-head for M12/d24 mm, for M14/d28 mm Round-head for M12/d26 mm (e.g. OE VAG-wheels) Flat-head with disc for CITROEN/PEUGEOT-vehicles M12x1,25 Flat-head for PORSCHE-original-wheels M14x1,5 Safety Guidelines (No. of turns for wheel screws) M12x1,5 = 6,5 turns = approx. 10 mm of load bearing shaft length M12x1,25 = 8,0 turns = approx. 10 mm of load bearing shaft length M12x1,75 = 6,5 turns = approx. 12 mm of load bearing shaft length M14x1,5 = 7,5 turns = approx. 12 mm of load bearing shaft length 1/2"UNF = 8,0 turns = approx. 11 mm of load bearing shaft length Please ensure that the wheel screws do not damage any part of the brake system (ABS sensors etc.) Turn the wheel first by hand and check clearance on the inside (max. tolerance for some vehicles is only 2 mm (RA Mercedes).
Note 18b: For the usage of these spacers certain specific technical requierements need to be fulfilled! Please check product information document TRAK_HINWEISE.pdf note 18b!

Product information (PDF) · Installation manual (PDF)

Vehicle Fitment

Make Model Chassis Models Years
Lancia Delta 831 All models 1979–1994
Lancia Prisma 831 All models 1983–1992
Lancia Thema 834 All models 1984–1994
Alfa Romeo 164 164 All models 1987–1998
Lancia Dedra 835 All models 1989–1999
Alfa Romeo 155 167 All models 1992–1997
Fiat Coupe 175 All models 1993–2000
Fiat Punto 176 All models 1993–2000
Lancia Delta 836 All models 1993–1999
Fiat Barchetta 183 All models 1995–2005
Fiat Brava 182 All models 1995–2002
Fiat Bravo 182 All models 1995–2001
Fiat Seicento / 600 187 All models 1997–2010
Fiat Punto 188 All models 1999–2012
Lancia Lybra 839 All models 1999–2005
Fiat Stilo 192 All models 2001–2008
Fiat Idea 350 All models 2003–2026
Lancia Ypsilon 843 All models 2003–2011
Lancia Musa 350 All models 2004–2012
Fiat Bravo 198 All models 2006–2016
