H&R TRAK+® Wheel Spacers 12mm (24mm per axle), 5x108, 65mm bore, Silver for Toyota, Vauxhall, Citroën, DS, Fiat, Opel + 2 more makes - 2435650

H&R SKU: 2435650
Regular price Price: £117.74
Sale ends in
Days
Hours
Minutes
Seconds
Accepted payment methods
  • American Express
  • Apple Pay
  • Bizum
  • Diners Club
  • Discover
  • Google Pay
  • Klarna
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Satispay
  • Shop Pay
  • Union Pay
  • Visa

Do you have questions about this product?

📞 Ask an Expert!

H&R TRAK+ wheel spacers push the wheels outward to improve stance, track width and clearance. Precision-machined and hub-centric for a perfect, vibration-free fit. Please note the correct bolt/cone type and length — longer wheel bolts are required for DR-system spacers and are ordered separately.

Features

  • Improved stance and wider track
  • Hub-centric, precision-machined
  • Application-specific fitment
  • TÜV-certified versions available

Specification

  • Thread Size: M12x1,25
  • Colour: silver
  • Thickness (mm): 12
  • Track widening per axle (mm): 24
  • Number of holes: 5
  • Bolt hole circle Ø (mm): 108
  • Registration: with TÜV® certificate

Please note additional information and vehicle-specific technical notes!
For cars with 5-hole wheels.
DR = The wheel spacer should be fitted between the wheel and the axial hub using longer bolts not supplied - please order separately. When ordering the longer bolts please state which cone type you require (i.e. taper, round, loose round or flat) and the required extra length. All screws for the DR systems have to be orderded separately.
All DR-Systems require longer wheel-bolts. These have to be ordered separately. When ordering wheel-bolts please follow these guidelines: If possible name the type of the wheel when ordering. New bolts must be longer than the original ones by half of the total Track-widening. For example: With a 30 mm DR-kit you will require bolts that are 15 mm longer than the original bolts. The bold-head must be identical to the existing bolt: Taper 60° Round-head for M12/d24 mm, for M14/d28 mm Round-head for M12/d26 mm (e.g. OE VAG-wheels) Flat-head with disc for CITROEN/PEUGEOT-vehicles M12x1,25 Flat-head for PORSCHE-original-wheels M14x1,5 Safety Guidelines (No. of turns for wheel screws) M12x1,5 = 6,5 turns = approx. 10 mm of load bearing shaft length M12x1,25 = 8,0 turns = approx. 10 mm of load bearing shaft length M12x1,75 = 6,5 turns = approx. 12 mm of load bearing shaft length M14x1,5 = 7,5 turns = approx. 12 mm of load bearing shaft length 1/2"UNF = 8,0 turns = approx. 11 mm of load bearing shaft length Please ensure that the wheel screws do not damage any part of the brake system (ABS sensors etc.) Turn the wheel first by hand and check clearance on the inside (max. tolerance for some vehicles is only 2 mm (RA Mercedes).
Note 18b: For the usage of these spacers certain specific technical requierements need to be fulfilled! Please check product information document TRAK_HINWEISE.pdf note 18b!

Product information (PDF) · Installation manual (PDF)

Vehicle Fitment

Make Model Chassis Models Years
Citroën XM Y3 All models 1989–1994
Peugeot 605 6B All models 1989–1999
Citroën XM Y4 All models 1994–2000
Volvo V70 P80 All models 1995–2000
Volvo S70 874 All models 1996–2000
Volvo S90 964 All models 1996–1998
Volvo V90 965 All models 1996–1998
Volvo C70 MK1 All models 1997–2005
Volvo V70 P2 All models 1999–2008
Volvo S60 P2 All models 2000–2010
Peugeot 407 6D All models 2004–2026
Citroën C5 C5 III All models 2008–2017
Peugeot 508 8 All models 2010–2018
Peugeot RCZ 4J All models 2010–2015
Citroën C4 Picasso C4 Picasso II All models 2013–2026
Peugeot 308 L All models 2013–2021
Citroën Jumpy MK3 All models 2016–2026
Citroën SpaceTourer All All models 2016–2026
Peugeot 3008 M All models 2016–2026
Peugeot 5008 P87 All models 2016–2026
Peugeot Expert K0 All models 2016–2026
Peugeot Traveller All All models 2016–2026
DS DS7 All All models 2017–2026
Opel Grandland A18 All models 2017–2026
Vauxhall Grandland A18 All models 2017–2026
Citroën Berlingo K9 All models 2018–2026
Citroën C5 Aircross All All models 2018–2026
Opel Combo E All models 2018–2026
Peugeot 508 R83 All models 2018–2026
Peugeot Partner K9 All models 2018–2026
Peugeot Rifter All All models 2018–2026
Vauxhall Combo E All models 2018–2026
Opel Vivaro K0 All models 2019–2026
Opel Zafira Life K0 All models 2019–2026
Toyota Proace City BPZ All models 2019–2026
Toyota Proace City Verso BKY All models 2019–2026
Opel Astra L All models 2021–2026
Peugeot 308 MK3 All models 2021–2026
Vauxhall Astra L All models 2021–2026
Fiat Doblo K9 All models 2022–2026
Fiat Scudo All All models 2022–2026
