H&R TRAK+® Wheel Spacers 13mm (26mm per axle), 5x112, 66.5mm bore, Silver for Mercedes, Infiniti & SsangYong - 2655665

H&R SKU: 2655665
Regular price Price: £117.74
Sale ends in
Days
Hours
Minutes
Seconds
Accepted payment methods
  • American Express
  • Apple Pay
  • Bizum
  • Diners Club
  • Discover
  • Google Pay
  • Klarna
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Satispay
  • Shop Pay
  • Union Pay
  • Visa

Do you have questions about this product?

📞 Ask an Expert!

H&R TRAK+ wheel spacers push the wheels outward to improve stance, track width and clearance. Precision-machined and hub-centric for a perfect, vibration-free fit. Please note the correct bolt/cone type and length — longer wheel bolts are required for DR-system spacers and are ordered separately.

Features

  • Improved stance and wider track
  • Hub-centric, precision-machined
  • Application-specific fitment
  • TÜV-certified versions available

Specification

  • Thread Size: M12x1,5
  • Colour: silver
  • Track widening per axle (mm): 26
  • Number of holes: 5
  • Bolt hole circle Ø (mm): 112
  • Registration: with TÜV® certificate

Please note additional information and vehicle-specific technical notes!
Not usable with steel-rims!
Only for the front axle.
DR = The wheel spacer should be fitted between the wheel and the axial hub using longer bolts not supplied - please order separately. When ordering the longer bolts please state which cone type you require (i.e. taper, round, loose round or flat) and the required extra length. All screws for the DR systems have to be orderded separately.
All DR-Systems require longer wheel-bolts. These have to be ordered separately. When ordering wheel-bolts please follow these guidelines: If possible name the type of the wheel when ordering. New bolts must be longer than the original ones by half of the total Track-widening. For example: With a 30 mm DR-kit you will require bolts that are 15 mm longer than the original bolts. The bold-head must be identical to the existing bolt: Taper 60° Round-head for M12/d24 mm, for M14/d28 mm Round-head for M12/d26 mm (e.g. OE VAG-wheels) Flat-head with disc for CITROEN/PEUGEOT-vehicles M12x1,25 Flat-head for PORSCHE-original-wheels M14x1,5 Safety Guidelines (No. of turns for wheel screws) M12x1,5 = 6,5 turns = approx. 10 mm of load bearing shaft length M12x1,25 = 8,0 turns = approx. 10 mm of load bearing shaft length M12x1,75 = 6,5 turns = approx. 12 mm of load bearing shaft length M14x1,5 = 7,5 turns = approx. 12 mm of load bearing shaft length 1/2"UNF = 8,0 turns = approx. 11 mm of load bearing shaft length Please ensure that the wheel screws do not damage any part of the brake system (ABS sensors etc.) Turn the wheel first by hand and check clearance on the inside (max. tolerance for some vehicles is only 2 mm (RA Mercedes).
Note 18b: For the usage of these spacers certain specific technical requierements need to be fulfilled! Please check product information document TRAK_HINWEISE.pdf note 18b!

Product information (PDF) · Installation manual (PDF)

Vehicle Fitment

Make Model Chassis Models Years
SsangYong Korando CK All models 2010–2026
Mercedes-Benz C-Class W205 All models 2013–2021
Mercedes-Benz GLA X156 All models 2013–2019
Mercedes-Benz S-Class W222 All models 2013–2020
Mercedes-Benz AMG GT C190 All models 2014–2021
Mercedes-Benz C-Class S205 All models 2014–2021
Mercedes-Benz S-Class C217 All models 2014–2020
Infiniti Q30 H15 All models 2015–2026
Mercedes-Benz C-Class C205 All models 2015–2023
Mercedes-Benz GLC X253 All models 2015–2022
Mercedes-Benz GLE C292 All models 2015–2019
Mercedes-Benz GLE W166 All models 2015–2018
Mercedes-Benz AMG GT R190 All models 2016–2021
Mercedes-Benz C-Class A205 All models 2016–2023
Mercedes-Benz E-Class C238 All models 2016–2026
Mercedes-Benz E-Class S213 All models 2016–2023
Mercedes-Benz E-Class W213 All models 2016–2023
Mercedes-Benz GLC C253 All models 2016–2023
Mercedes-Benz SLC R172 All models 2016–2026
Mercedes-Benz CLS C257 All models 2017–2026
Mercedes-Benz E-Class A238 All models 2017–2026
Mercedes-Benz A-Class V177 All models 2018–2026
Mercedes-Benz A-Class W177 All models 2018–2026
Mercedes-Benz AMG GT X290 All models 2018–2026
Mercedes-Benz GLE V167 All models 2018–2026
Mercedes-Benz CLA C118 All models 2019–2026
Mercedes-Benz CLA X118 All models 2019–2026
Mercedes-Benz GLE C167 All models 2019–2026
Mercedes-Benz GLA H247 All models 2020–2026
Mercedes-Benz EQB X243 All models 2021–2026
