H&R TRAK+® Wheel Spacers 20mm (40mm per axle), 4x100, 56.6mm bore, Silver for Vauxhall, Chevrolet, Daewoo, Fiat & Opel - 4024566

H&R SKU: 4024566
Regular price Price: £133.56
Sale ends in
Days
Hours
Minutes
Seconds
Accepted payment methods
  • American Express
  • Apple Pay
  • Bizum
  • Diners Club
  • Discover
  • Google Pay
  • Klarna
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Satispay
  • Shop Pay
  • Union Pay
  • Visa

Do you have questions about this product?

📞 Ask an Expert!

H&R TRAK+ wheel spacers push the wheels outward to improve stance, track width and clearance. Precision-machined and hub-centric for a perfect, vibration-free fit. Please note the correct bolt/cone type and length — longer wheel bolts are required for DR-system spacers and are ordered separately.

Features

  • Improved stance and wider track
  • Hub-centric, precision-machined
  • Application-specific fitment
  • TÜV-certified versions available

Specification

  • Thread Size: M12x1,5
  • Colour: silver
  • Thickness (mm): 20
  • Track widening per axle (mm): 40
  • Number of holes: 4
  • Bolt hole circle Ø (mm): 100
  • Registration: with TÜV® certificate

For all cars with 4-hole wheel.
Please note additional information and vehicle-specific technical notes!
DR = The wheel spacer should be fitted between the wheel and the axial hub using longer bolts not supplied - please order separately. When ordering the longer bolts please state which cone type you require (i.e. taper, round, loose round or flat) and the required extra length. All screws for the DR systems have to be orderded separately.
All DR-Systems require longer wheel-bolts. These have to be ordered separately. When ordering wheel-bolts please follow these guidelines: If possible name the type of the wheel when ordering. New bolts must be longer than the original ones by half of the total Track-widening. For example: With a 30 mm DR-kit you will require bolts that are 15 mm longer than the original bolts. The bold-head must be identical to the existing bolt: Taper 60° Round-head for M12/d24 mm, for M14/d28 mm Round-head for M12/d26 mm (e.g. OE VAG-wheels) Flat-head with disc for CITROEN/PEUGEOT-vehicles M12x1,25 Flat-head for PORSCHE-original-wheels M14x1,5 Safety Guidelines (No. of turns for wheel screws) M12x1,5 = 6,5 turns = approx. 10 mm of load bearing shaft length M12x1,25 = 8,0 turns = approx. 10 mm of load bearing shaft length M12x1,75 = 6,5 turns = approx. 12 mm of load bearing shaft length M14x1,5 = 7,5 turns = approx. 12 mm of load bearing shaft length 1/2"UNF = 8,0 turns = approx. 11 mm of load bearing shaft length Please ensure that the wheel screws do not damage any part of the brake system (ABS sensors etc.) Turn the wheel first by hand and check clearance on the inside (max. tolerance for some vehicles is only 2 mm (RA Mercedes).

Product information (PDF) · Installation manual (PDF)

Vehicle Fitment

Make Model Chassis Models Years
Opel Kadett D All models 1979–1984
Vauxhall Astra D All models 1979–1984
Opel Ascona C All models 1981–1988
Vauxhall Cavalier J82 All models 1981–1988
Opel Corsa A All models 1982–1994
Vauxhall Nova All All models 1982–1994
Opel Kadett E All models 1984–1993
Vauxhall Astra E All models 1984–1993
Opel Vectra A All models 1988–1995
Vauxhall Cavalier A All models 1988–1995
Opel Calibra A All models 1989–1997
Vauxhall Calibra A All models 1990–1997
Daewoo Espero KLEJ All models 1991–1999
Opel Astra F All models 1991–2001
Vauxhall Astra F All models 1991–2001
Vauxhall Corsa B All models 1992–2000
Opel Corsa B All models 1993–2002
Opel Tigra A All models 1994–2000
Daewoo Nexia KLETN All models 1995–2026
Opel Vectra B All models 1995–2003
Daewoo Lanos KLATF All models 1997–2026
Daewoo Nubira J100 All models 1997–2026
Opel Astra G All models 1998–2009
Vauxhall Astra G All models 1998–2005
Opel Corsa C All models 2000–2009
Vauxhall Corsa C All models 2000–2007
Daewoo Nubira J200 All models 2003–2026
Opel Meriva A All models 2003–2010
Opel Astra H All models 2004–2014
Opel Tigra B All models 2004–2010
Vauxhall Astra H All models 2004–2012
Chevrolet Nubira J200 All models 2005–2011
Fiat Grande Punto 199 All models 2005–2026
Opel Corsa D All models 2006–2014
Vauxhall Corsa D All models 2006–2014
Fiat Punto 199 All models 2012–2026
