H&R TRAK+® Wheel Spacers 20mm (40mm per axle), 4x100, 60.1mm bore, Silver for Nissan, Dacia, Renault & Smart - 40264601

H&R SKU: 40264601
Regular price Price: $149.00
Sale ends in
Days
Hours
Minutes
Seconds
Accepted payment methods
  • American Express
  • Apple Pay
  • Bizum
  • Diners Club
  • Discover
  • Google Pay
  • Klarna
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Satispay
  • Shop Pay
  • Union Pay
  • Visa

Do you have questions about this product?

📞 Ask an Expert!

H&R TRAK+ wheel spacers push the wheels outward to improve stance, track width and clearance. Precision-machined and hub-centric for a perfect, vibration-free fit. Please note the correct bolt/cone type and length — longer wheel bolts are required for DR-system spacers and are ordered separately.

Features

  • Improved stance and wider track
  • Hub-centric, precision-machined
  • Application-specific fitment
  • TÜV-certified versions available

Specification

  • Thread Size: M12x1,5
  • Colour: silver
  • Thickness (mm): 20
  • Track widening per axle (mm): 40
  • Number of holes: 4
  • Bolt hole circle Ø (mm): 100
  • Registration: without TÜV® certificate

For all cars with 4-hole wheel.
Not usable with steel-rims!
Please note additional information and vehicle-specific technical notes!
DR = The wheel spacer should be fitted between the wheel and the axial hub using longer bolts not supplied - please order separately. When ordering the longer bolts please state which cone type you require (i.e. taper, round, loose round or flat) and the required extra length. All screws for the DR systems have to be orderded separately.
All DR-Systems require longer wheel-bolts. These have to be ordered separately. When ordering wheel-bolts please follow these guidelines: If possible name the type of the wheel when ordering. New bolts must be longer than the original ones by half of the total Track-widening. For example: With a 30 mm DR-kit you will require bolts that are 15 mm longer than the original bolts. The bold-head must be identical to the existing bolt: Taper 60° Round-head for M12/d24 mm, for M14/d28 mm Round-head for M12/d26 mm (e.g. OE VAG-wheels) Flat-head with disc for CITROEN/PEUGEOT-vehicles M12x1,25 Flat-head for PORSCHE-original-wheels M14x1,5 Safety Guidelines (No. of turns for wheel screws) M12x1,5 = 6,5 turns = approx. 10 mm of load bearing shaft length M12x1,25 = 8,0 turns = approx. 10 mm of load bearing shaft length M12x1,75 = 6,5 turns = approx. 12 mm of load bearing shaft length M14x1,5 = 7,5 turns = approx. 12 mm of load bearing shaft length 1/2"UNF = 8,0 turns = approx. 11 mm of load bearing shaft length Please ensure that the wheel screws do not damage any part of the brake system (ABS sensors etc.) Turn the wheel first by hand and check clearance on the inside (max. tolerance for some vehicles is only 2 mm (RA Mercedes).

Product information (PDF) · Installation manual (PDF)

Vehicle Fitment

Make Model Chassis Models Years
Renault Renault 5 MK1 All models 1972–1985
Renault 9 L42 All models 1981–1989
Renault 11 B/C37 All models 1983–1988
Renault Espace Espace I All models 1984–1992
Renault 21 L48 All models 1986–1995
Renault 19 B/C53 All models 1988–2001
Renault Clio Clio I All models 1990–1998
Renault Espace Espace II All models 1991–1996
Renault Safrane B54 All models 1992–2000
Renault Laguna B56 All models 1993–2001
Renault Twingo Twingo I All models 1993–2007
Renault Megane Megane I All models 1995–2008
Renault Scénic Scénic I All models 1996–2003
Renault Kangoo Kangoo I All models 1997–2026
Renault Clio Clio II All models 1998–2016
Nissan Micra K12 All models 2002–2010
Renault Megane Megane II All models 2002–2026
Renault Scénic Scénic II All models 2003–2010
Dacia Logan LS_ All models 2004–2026
Renault Modus P All models 2004–2013
Renault Clio Clio III All models 2005–2014
Renault Twingo Twingo II All models 2007–2014
Dacia Sandero BS_ All models 2008–2013
Renault Wind N All models 2010–2013
Renault Clio Clio IV All models 2012–2021
Smart Forfour 453 All models 2014–2026
Smart Fortwo 453 All models 2014–2026
Renault Clio Clio V All models 2019–2026
