H&R TRAK+® Wheel Spacers - B16234571

H&R SKU: B16234571
Regular price Price: $83.00
Sale ends in
Days
Hours
Minutes
Seconds
Accepted payment methods
  • American Express
  • Apple Pay
  • Bizum
  • Diners Club
  • Discover
  • Google Pay
  • Klarna
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Satispay
  • Shop Pay
  • Union Pay
  • Visa

Do you have questions about this product?

📞 Ask an Expert!

H&R TRAK+ wheel spacers push the wheels outward to improve stance, track width and clearance. Precision-machined and hub-centric for a perfect, vibration-free fit. Please note the correct bolt/cone type and length — longer wheel bolts are required for DR-system spacers and are ordered separately.

Features

  • Improved stance and wider track
  • Hub-centric, precision-machined
  • Application-specific fitment
  • TÜV-certified versions available

Specification

  • Thread Size: M12x1,5
  • Colour: black
  • Thickness (mm): 8
  • Track widening per axle (mm): 16
  • Number of holes: 4
  • Registration: with TÜV® certificate

Please note additional information and vehicle-specific technical notes!
DR = The wheel spacer should be fitted between the wheel and the axial hub using longer bolts not supplied - please order separately. When ordering the longer bolts please state which cone type you require (i.e. taper, round, loose round or flat) and the required extra length. All screws for the DR systems have to be orderded separately.
For all cars with 4-hole wheel.
All DR-Systems require longer wheel-bolts. These have to be ordered separately. When ordering wheel-bolts please follow these guidelines: If possible name the type of the wheel when ordering. New bolts must be longer than the original ones by half of the total Track-widening. For example: With a 30 mm DR-kit you will require bolts that are 15 mm longer than the original bolts. The bold-head must be identical to the existing bolt: Taper 60° Round-head for M12/d24 mm, for M14/d28 mm Round-head for M12/d26 mm (e.g. OE VAG-wheels) Flat-head with disc for CITROEN/PEUGEOT-vehicles M12x1,25 Flat-head for PORSCHE-original-wheels M14x1,5 Safety Guidelines (No. of turns for wheel screws) M12x1,5 = 6,5 turns = approx. 10 mm of load bearing shaft length M12x1,25 = 8,0 turns = approx. 10 mm of load bearing shaft length M12x1,75 = 6,5 turns = approx. 12 mm of load bearing shaft length M14x1,5 = 7,5 turns = approx. 12 mm of load bearing shaft length 1/2"UNF = 8,0 turns = approx. 11 mm of load bearing shaft length Please ensure that the wheel screws do not damage any part of the brake system (ABS sensors etc.) Turn the wheel first by hand and check clearance on the inside (max. tolerance for some vehicles is only 2 mm (RA Mercedes).
These spacers without a double-sided centering are only useable for cars with a sufficient length of the centering to be able to center the wheels enough despite the spacer.

Product information (PDF) · Installation manual (PDF)

Vehicle Fitment

Make Model Chassis Models Years
Volkswagen Golf MK1 All models 1974–1993
Volkswagen Scirocco 53 All models 1974–1980
Volkswagen Polo 86 All models 1975–1981
Audi 80 B2 All models 1978–1987
Volkswagen Jetta MK1 All models 1978–1984
Volkswagen Passat B2 All models 1979–1989
Audi Coupe B2 All models 1980–1988
Volkswagen Scirocco 53B All models 1980–1992
Volkswagen Polo 86C All models 1981–1994
Audi 100 C3 All models 1982–1991
BMW 3 Series E30 316, 316i, 318i, 318is, 320i, 320is, 323i, 324d, 324td, 325e, 325i 1982–1994
Audi 200 C3 All models 1983–1991
Volkswagen Golf MK2 All models 1983–1992
Volkswagen Jetta MK2 All models 1984–1992
Audi 80 B3 All models 1986–2026
Audi 90 B3 All models 1987–1991
Audi Coupe B3 All models 1988–1996
Skoda Favorit 781 All models 1988–1997
Volkswagen Corrado 53I All models 1988–1995
Volkswagen Passat B3 All models 1988–1993
Audi 80 B4 All models 1991–1996
Audi Cabriolet B4 All models 1991–2000
Seat Toledo 1L All models 1991–1999
Volkswagen Golf MK3 All models 1991–1999
Volkswagen Vento 1H All models 1991–1998
Seat Cordoba 6K All models 1993–2002
Seat Ibiza 6K All models 1993–2002
Skoda Felicia 6U1 All models 1994–2001
Volkswagen Passat B4 All models 1994–1997
Volkswagen Polo 6N All models 1994–2006
Seat Arosa 6H All models 1997–2004
Volkswagen Lupo 6X All models 1998–2005
