H&R TRAK+® Wheel Spacers 18mm (36mm per axle), 5x130, 71.6mm bore, Black for Audi, VW & Porsche - B36957161

H&R SKU: B36957161
Regular price Price: $193.00
Sale ends in
Days
Hours
Minutes
Seconds
Accepted payment methods
  • American Express
  • Apple Pay
  • Bizum
  • Diners Club
  • Discover
  • Google Pay
  • Klarna
  • Maestro
  • Mastercard
  • MB WAY
  • PayPal
  • Satispay
  • Shop Pay
  • Union Pay
  • Visa

Do you have questions about this product?

📞 Ask an Expert!

H&R TRAK+ wheel spacers push the wheels outward to improve stance, track width and clearance. Precision-machined and hub-centric for a perfect, vibration-free fit. Please note the correct bolt/cone type and length — longer wheel bolts are required for DR-system spacers and are ordered separately.

Features

  • Improved stance and wider track
  • Hub-centric, precision-machined
  • Application-specific fitment
  • TÜV-certified versions available

Specification

  • Thread Size: M14x1,5
  • Colour: black
  • Thickness (mm): 18
  • Track widening per axle (mm): 36
  • Number of holes: 5
  • Bolt hole circle Ø (mm): 130
  • Registration: with TÜV® certificate

Please note additional information and vehicle-specific technical notes!
DR = The wheel spacer should be fitted between the wheel and the axial hub using longer bolts not supplied - please order separately. When ordering the longer bolts please state which cone type you require (i.e. taper, round, loose round or flat) and the required extra length. All screws for the DR systems have to be orderded separately.
All DR-Systems require longer wheel-bolts. These have to be ordered separately. When ordering wheel-bolts please follow these guidelines: If possible name the type of the wheel when ordering. New bolts must be longer than the original ones by half of the total Track-widening. For example: With a 30 mm DR-kit you will require bolts that are 15 mm longer than the original bolts. The bold-head must be identical to the existing bolt: Taper 60° Round-head for M12/d24 mm, for M14/d28 mm Round-head for M12/d26 mm (e.g. OE VAG-wheels) Flat-head with disc for CITROEN/PEUGEOT-vehicles M12x1,25 Flat-head for PORSCHE-original-wheels M14x1,5 Safety Guidelines (No. of turns for wheel screws) M12x1,5 = 6,5 turns = approx. 10 mm of load bearing shaft length M12x1,25 = 8,0 turns = approx. 10 mm of load bearing shaft length M12x1,75 = 6,5 turns = approx. 12 mm of load bearing shaft length M14x1,5 = 7,5 turns = approx. 12 mm of load bearing shaft length 1/2"UNF = 8,0 turns = approx. 11 mm of load bearing shaft length Please ensure that the wheel screws do not damage any part of the brake system (ABS sensors etc.) Turn the wheel first by hand and check clearance on the inside (max. tolerance for some vehicles is only 2 mm (RA Mercedes).
The original wheel screw which sticks out of the inner side of the wheel needs to have a permanent thread and it´s length has to be smaller than the thickness of the spacer.

Product information (PDF) · Installation manual (PDF)

Vehicle Fitment

Make Model Chassis Models Years
Audi Q7 4L All models 2006–2015
Volkswagen Touareg 7L All models 2002–2010
Volkswagen Touareg 7P All models 2010–2018
Porsche Boxster 986 All models 1996–2004
Porsche 911 996 All models 1997–2005
Porsche Cayenne 955 All models 2002–2006
Porsche 911 997 All models 2004–2012
Porsche Boxster 987 All models 2004–2012
Porsche Cayman 987 All models 2005–2013
Porsche Cayenne 957 All models 2007–2010
Porsche Panamera 970 All models 2009–2016
Porsche Cayenne 958 All models 2010–2018
Porsche 911 991 All models 2011–2020
Porsche Boxster 981 All models 2012–2016
Porsche Cayman 981 All models 2013–2016
Porsche Boxster 982 All models 2016–2026
Porsche Cayman 982 All models 2016–2026
